MB48B200BTSG - Circuit Breaker

The Circuit Breaker is a high-performance electrical device designed to protect your electrical system from overloads and short circuits. With a 200A current rating, it is ideal for residential and light commercial applications. This breaker features 8 circuits and is designed for single-phase systems, providing flexibility for various wiring configurations. The wire size range of 6 AWG to 350 Kcmil allows for a wide range of compatible wire sizes, offering versatility in installation.

The unit is equipped with an aluminum bus material, known for its lightweight and durable properties. It features 4 jaws and 1 socket for secure electrical connections and is rated for 120/240 V AC. Measuring 7 inches in height, 25 inches in length, and 23.5 inches in width, it provides ample space for wiring and installation. The breaker weighs 44 lbs, ensuring a sturdy and reliable solution for electrical protection.

Key Features:

• Type: Circuit Breaker
• Current Rating: 200 A
• Dimensions: Height: 7 in, Length: 25 in, Width: 23.5 in
• Wire Size: 6 AWG to 350 Kcmil
• Voltage Rating: 120/240 V AC
• Phase: 1 Phase
• Circuits: 8 Circuits
• Bus Material: Aluminum for durability and lightweight construction
• Jaws: 4 Jaws
• Socket: 1 Socket
• Weight: 44 lbs
• Application: Ideal for residential and light commercial use

This Circuit Breaker offers strong protection, efficient wiring management, and reliability, making it an excellent choice for safeguarding your electrical system.

Documents:

Brochures
Eaton Emergency Disconnect Options at a Glance

Catalogs
Residential and Light Commercial, Metering Products, Volume 1 Tab 4

Specifications and datasheets
Eaton Specification Sheet - MB48B200BTSG
