GHB1030 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker provides reliable and efficient circuit protection for both industrial and commercial applications. This G-frame breaker is equipped with fixed thermal and fixed magnetic trip types, ensuring continuous, dependable protection. With a 30A rating, it operates at 277 Vac and 125 VDC, making it suitable for both alternating and direct current systems. The breaker also offers a high short-circuit withstand rating of 14kAIC at 277 Vac, ensuring strong defense against electrical faults. Designed for 50/60 Hz applications, this single-pole breaker features an easy installation process, making it ideal for protecting a wide range of electrical circuits.

Key Features:

• Fixed thermal and magnetic trip types for consistent protection
• Single-pole configuration for individual circuit protection
• 30A rating with a short-circuit withstand rating of 14kAIC at 277 Vac
• Operates at 277 Vac and 125 VDC
• Compatible with 50/60 Hz applications

The Eaton Series C breaker is the perfect solution for ensuring safety and reliability in electrical systems, offering high protection against faults and overloads.

Documents:

Application notes
Application of Tap Rules to Molded Case Breaker Terminals

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
