FD3050 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker is a high-performance solution for protecting electrical circuits in industrial and commercial settings. Designed with a 50 A rating, this three-pole breaker offers reliable overcurrent protection for both 600 Vac and 250 VDC applications. The fixed thermal and fixed magnetic trip types deliver enhanced safety and precision, making it ideal for demanding environments.

Key Features:

• 50 A current rating for reliable circuit protection
• Fixed thermal and magnetic trip types for consistent performance
• Dimensions: 4.75 in overall height, 4.25 in overall length, 2 in overall width
• Suitable for 600 Vac and 250 VDC applications

This Eaton Series C Complete Molded Case Circuit Breaker ensures dependable protection and is well-suited for use on the load side of electrical systems, delivering superior safety and operational reliability.

Documents:

Application notes

Application of Multi-Wire Terminals for Molded Case Circuit Breakers

UL listed 100%-rated molded case circuit breakers
Catalogs

Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Multimedia

Circuit breakers explained

Circuit Breakers Explained
Specifications and datasheets

Series C G-Frame molded case circuit breakers time current curves
