EHD3050L - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker provides reliable protection for electrical systems, designed for industrial and commercial use. With a 50A rating, this F-frame circuit breaker ensures effective circuit protection through fixed thermal and fixed magnetic trip types. It boasts impressive short-circuit withstand ratings of 18kAIC at 240 Vac and 14kAIC at 480 Vac, making it ideal for high-capacity applications. This three-pole breaker operates in both 50 Hz and 60 Hz systems and is easy to install with its line and load terminals. Its robust design delivers superior performance and protection in diverse electrical environments.

Key Features:

• Fixed thermal and magnetic trip types for reliable circuit protection
• Three-pole configuration for flexible electrical protection
• 50A rating with high short-circuit withstand ratings (18kAIC at 240 Vac, 14kAIC at 480 Vac)
• Compatible with 50/60 Hz applications
• Simple installation with line and load terminals

This Eaton Series C breaker is the perfect solution for ensuring safety and reliability in demanding electrical systems.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
