Victron Energy 3000 VA Fan Assisted Pure Sine Wave Inverter

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds. SinusMax - Superior engineering. Developed for professional duty, this range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Features

• Extra start-up power
• Virtually unlimited power thanks to parallel and 3-phase operation capability
• To transfer the load to another AC source: the automatic transfer switch
• Communications interface


Specifications

• Length: 362 mm
• Width: 258 mm
• Depth: 218 mm
• Input Voltage: 9.5-66 V
• Output Voltage: 230 Vac
• Power Rating: 3000 VA
• Efficiency: 93/94/95%
• Frequency Rating: 50 Hz
• Cooling Type: Fan Assisted
• Power Factor: 1
• Connection Type: Screw Terminal
• Temperature Rating: -40 to 65°F


Documents

• Specification Sheet
