Sun Xtender, PVX-6240T, 2V, AGM Deep Cycle Solar Battery

Since 1987, Sun Xtender has been designing valve regulated lead acid batteries with AGM construction (VRLA-AGM).The AGM construction means no water replenishment ever.Utilizing pure lead calcium grids, the plates are thicker than the industry standard for longer cycle life, increased reliability and power. The low impedance AGM design allows for excellent charge acceptance and there is no current limit required with controlled voltage charging.The Sun Xtender product line features proprietary PolyGuard® Microporous Polyethylene Separators, shielding the positive plates against shorting, shock or vibration. No other manufacturers offer this dual layer insulation protection feature.Sun Xtender battery covers and containers are uniquely molded with high impact, reinforced copolymer polypropylene and are designed with thick end walls to prevent bulging. The copper alloy T Terminals are corrosion resistant and are supplied with silicon bronze bolts and washers.All Sun Xtender Batteries ship Hazmat Exempt.

Features

• Copper Alloy Terminals for improved electrical connections
• No exposed lead terminals to improve environmental safety and health
• Threaded insert terminals are recessed to prevent short circuits across battery connections
• New cover is flat top design. No protruding or exposed vent valves
• Built in lifting handles
• Reinforced container walls to reduce bulging
• High impact strength copolymer polypropylene case and cover
• Completely Sealed Valve Regulated Construction
• Immobilized electrolyte non-spillable
• Maintenance free design never requires watering
• Absorbed Glass Mat (AGM) Micro-porous Glass Separators retain electrolyte
• Flame arresting pressure regulated safety valves
• Positive plates - proprietary lead calcium alloy- negatives plates - lead calcium
• Low Self Discharge Rate Approximately 1 % per month at 25 deg C (77 deg F)
• Classified as "Non-spillable battery" for transport
• Most Part Numbers comply with DOT HMR49, non-hazardous materials

Specifications

• Type: Deep Cycle
• Series/Model: PVX
• Voltage Rating: 2 V
• Nominal Capacity:
  • 390 Ah at 1 hr
  • 492 Ah at 2 hr
  • 510 Ah at 4 hr
  • 558 Ah at 8 hr
  • 624 Ah at 24 hr
  • 710 Ah at 100 hr
• Dimensions: 8.93 in (L) x 12 in (W) x 8.13 in (H)
• Material: Copolymer Polypropylene
• Battery Group Size: 27
• Operating Temperature: -40 to 72°C
• Self Discharge Rate: ~1% per Month at 25°C
• Positive Plates: Proprietary Lead Calcium Alloy
• Negative Plates: Lead Calcium
• Terminal: Copper Alloy
• Technology: Absorbed Glass Mat (AGM)
• Standards: UL Listed
• Warranty: Limited
• Weight: 65 lb

Documents

• Specification Sheet
• Technical Manual
• Warranty Information
