MidNite Solar MNEDC175 175A Circuit Breaker

All MidNite circuit breakers are rated for 100% continuous duty. Midnight's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting. These are single-pole panel-mount breakers with stud terminals that require ring terminals on the wires connected to them (except the two items with lugs). Breakers up through 80 A can be used in the Conext XW+ Distribution Panel. The 100 A and larger DC breakers fit in the OutBack Power FLEXware enclosures and MidNite E-Panels. Rated for 125 VDC only (except the 60 A lug breaker, which is rated at 160 VDC). MidNite breaker models ending in "RT" are remote trip breakers that can be used with the MNBDM for rapid shutdown.

Features

• 3500-Watt pure sine wave inverter output with 7000-Watt surge-features user-configurable battery charger (120 Amp maximum), switchable frequencies (50 Hz/60 Hz), and an optional power-saving mode
• Equipped with state of the art MPPT technology, boasting an efficiency of up to 99%, and a powerful bypass function with UPS
• Preset battery modes for 48-Volt AGM/sealed, gel, flooded, and lithium batteries, includes a user mode for custom inputs to work with virtually all battery types
• 4 charging modes - PV priority, utility priority, hybrid charging, and solar only, 3 load output modes: PV priority, utility priority, and inverter only


Specifications

• Type: Non-Polarized
• Series/Model: MNEDC
• Voltage Rating: 150 VDC
• Current Rating: 175 A
• Number of Poles: 1
• Mounting Type: Panel
• Interrupt Rating: 50000 AIC at 125 VDC
• Torque Rating: 15 ft-lb
• Enclosure Rating: Type 1 (Indoor)
• Includes: Two 10-32 X 3/8 Pan Head Phillips Mounting Screws
• Standards: ETL Listed
• Warranty: 5 Years
• Weight: 3 lb


Documents

• Specification Sheet
