MidNite Solar MNEDC 250 A Non-Polarized Circuit Breaker

All MidNite circuit breakers are rated for 100% continuous duty. Midnight's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting.These are single-pole panel-mount breakers with stud terminals that require ring terminals on the wires connected to them (except the two items with lugs). Breakers up through 80 A can be used in the Conext XW+ Distribution Panel. The 100 A and larger DC breakers fit in the OutBack Power FLEXware enclosures and MidNite E-Panels. Rated for 125 VDC only (except the 60 A lug breaker, which is rated at 160 VDC). MidNite breaker models ending in "RT" are remote trip breakers that can be used with the MNBDM for rapid shutdown.

Features

• 250 A. 125 VDC panel mount. 10000 AIC. Breaker Torque Value: 30 In-Lbs (3.4NM). Size: 3/4 in W, 1/4 in studs for Electrical connection


Specifications

• Type: Non-Polarized
• Series/Model: MNEDC
• Voltage Rating: 125 VDC
• Current Rating: 250 A
• Number of Poles: 1
• Mounting Type: Panel
• Interrupt Rating: 50000 AIC
• Torque Rating: 15 ft-lb
• Enclosure Rating: Type 1 (Indoor)
• Includes: 3/8 in Studs, (2) 10-32 X 3/8 Pan Head Phillips Mounting Screws
• Dimensions: 1.5 in Width
