GHC2020 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker (G-Frame, GHC) is a high-performance, reliable protection device designed for electrical systems. This two-pole, 20A breaker provides both fixed thermal and fixed magnetic trip types, ensuring comprehensive protection against overcurrent and short circuits. Ideal for use in both AC and DC applications, it is suitable for systems operating at 480Y/277 Vac or 125/250 VDC.

Key Features:

• Breaker Type: Complete Molded Case Circuit Breaker
• Frame Type: G-Frame (GHC) for high durability
• Trip Type: Fixed Thermal, Fixed Magnetic for reliable protection
• Poles: Two-Pole, providing dual-phase protection
• Current Rating: 20A for efficient circuit protection
• Voltage Rating:
• 480Y/277 Vac for three-phase systems
• 125/250 VDC for DC systems
• Interrupting Rating:
• 65 kAIC at 240 Vac
• 14 kAIC at 480Y/277 Vac, ensuring reliable interruption of high fault currents
• Frequency: 50/60 Hz
• Applications: Suitable for a wide range of industrial, commercial, and residential applications, ensuring protection of electrical circuits and systems from overloads and short circuits.

This Eaton Series C Circuit Breaker is designed to meet rigorous standards and provide reliable protection, ensuring the safety and longevity of your electrical systems. It is an essential component for applications requiring robust protection in both AC and DC environments, with excellent interrupting capabilities for enhanced system safety.
