EGE3040FFG - Eaton Series G Molded Case Circuit Breaker

Eaton Series G Molded Case Circuit Breaker is engineered for optimal performance in protecting electrical systems. This three-pole breaker, with a fixed thermal and fixed magnetic trip, is designed to safeguard circuits from overloads and short circuits. Rated for 40 A, it features impressive interrupting ratings for high-capacity systems, ensuring protection in a wide range of applications. Its ability to operate at multiple voltages, including 600Y/347 Vac and 480 Vac, makes it a versatile choice for various environments.

Key Features:

• Rated for 40 A to provide robust circuit protection
• Fixed thermal and magnetic trip for consistent performance
• Three-pole configuration for comprehensive protection
• High interrupting ratings: 35 Kaic at 240 Vac, 25 Kaic at 480 Vac, and 18 Kaic at 600Y/347 Vac
• Suitable for line and load configurations, operating at 50/60 Hz

This Eaton Series G Molded Case Circuit Breaker ensures reliable electrical protection in demanding applications, providing safety and peace of mind.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers
Application of Tap Rules to Molded Case Breaker Terminals
Brochures
Current limiting molded case circuit breaker module for series G, JG and CL

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Specifications and datasheets
MOEM MCCB product selection guide
