CHP12L200R - Eaton CH Main Lug Loadcenters

The Eaton CH Main Lug Loadcenter is a durable and efficient power distribution solution tailored for residential and light commercial outdoor applications. Featuring a weather-resistant NEMA 3R metallic enclosure, this main lug-only unit is ideal for overhead service installations where exposure to environmental elements is expected.

Rated at 200A, this loadcenter supports 24 circuits and 12 spaces, offering ample capacity for single-phase, three-wire systems. It includes a factory-installed cover for added protection and simplified setup. With a copper bus, this loadcenter provides excellent conductivity and long-term performance while maintaining compatibility with Eaton CH breakers.

Key Features:

• Type: CH Main Lug Loadcenter (Cover Included)
• Amp Rating: 200 A
• Enclosure Rating: NEMA 3R for outdoor use
• Material: Metallic with copper bus
• Phase/Wire: Single-phase, three-wire
• Circuit Capacity: 24 circuits, 12 spaces
• Bus Material: Copper for superior conductivity
• Feed Type: Overhead

This Eaton CH Main Lug Loadcenter ensures a reliable and rugged solution for outdoor electrical distribution, combining safety, flexibility, and long-lasting copper performance.

Documents:

Specifications and datasheets
Eaton Specification Sheet - CHP12L200R

Warranty guides
Eaton type CH circuit breaker limited warranty June 2024
