BAB2100 - Thermal Magnetic Circuit Breaker

The Thermal Magnetic Circuit Breaker is engineered to provide reliable protection against overcurrent and short-circuit conditions. With a 100 A rating and a non-interchangeable tripping mechanism, it offers consistent, secure operation for 120/240V AC systems. The bolt-on design ensures quick and reliable installation.

Key Features:

• 100 A current rating for high-capacity circuits
• Non-interchangeable tripping mechanism for enhanced durability
• Bolt-on installation for secure and easy setup
• Dimensions: 4.8 in overall height, 3.9 in overall length
• Lightweight design at only 0.7 lb

This circuit breaker is a trusted choice for electrical safety and system reliability in commercial and residential applications.

Documents:

Multimedia

Circuit Breakers Explained
Specifications and datasheets

Eaton Specification Sheet - BAB2100
