Rich Solar 60 Amp MPPT Solar Charge Controller

Features

• Automatically detects 12V or 24V DC system voltages
• Compatible with various deep cycle battery options: Sealed, Gel, Flooded, and Lithium
• Innovative MPPT technology with high tracking efficiency up to 99% and peak conversion efficiency of 98%
• Electronic protection against reverse polarity, overcharging, over-discharging, overload, short-circuiting, and reverse current
• LCD screen and multiple LED indicators for displaying system operation information, customizable parameters, and error codes
• Features diverse load control; also capable of charging over-discharged lithium batteries
• Die-cast aluminum design allows for efficient heat dissipation
• RS232 port to communicate with BT-1 Bluetooth module


Specifications

• Type: MPPT
• Operating Temperature: -31 to 113°F (-35 to 45°C)
• Load Current Rating: 20 A
• Battery Current Rating: 60 A
• Maximum Solar Voltage: 150 V Input
• Discharge Circuit Voltage Drop: ≤0.15 V
• Charge Circuit Voltage Drop: ≤0.26 V
• Terminal Size: 4 AWG
• Maximum Solar Input Power:
  • 800 W at 12 V
  • 1600 W at 24 V
  • 2400 W at 36 V
  • 3200 W at 48 V
• Dimensions: 11.2 in x 8.1 in x 4 in
• Standards: UL Listed, ETL Listed, PV Cycle, MCS, IEC, TUV
• Weight: 7.9 lb
• Warranty: 2 Years


Documents

• Owners/User Manual
