Enphase Energy IQ7A Series 366 VA Natural Convection Cooling Microinverter with Q-DCC Connection

The high-powered Enphase IQ7A Microinverter dramatically simplifies the installation process while achieving high system efficiency for systems with 60-cell, 66-cell, and 72-cell modules. Part of the Enphase IQ System, the IQ7A Microinverter integrates with Enphase IQ Battery, the Enphase IQ Gateway, and the Enphase App monitoring and analysis software. The IQ Microinverters extend the reliability standards set forth by previous generations and undergo over a million hours of power-on testing, enabling Enphase to provide an industry-leading warranty of up to 25 years.

Features

• 97% CEC efficiency
• Faster installation with improved, lighter two-wire cabling
• Built-in rapid shutdown compliant (NEC 2014, 2017, 2020)
• Complies with advanced grid support, voltage, and frequency ride-through requirements
• Remotely updates to respond to changing grid requirements
• Configurable for variable grid profiles
• More than a million hours of testing


Specifications

• Series: IQ7A
• Overall Length: 212 mm
• Overall Width: 175 mm
• Overall Depth: 30 mm
• Input Voltage: 18-58 V
• Power Rating: 366 VA
• Input Current: 10.2 A
• Amperage Rating: 1.45/1.39 A
• Efficiency: 97%
• Frequency Rating: 60 Hz
• Power Factor: 1
• Cooling Type: Natural Convection
• Temperature Rating: -40 to 60 deg F
• Output Voltage: 240/211-264 V, 208/183-229 V
• Connection Type: Q-DCC


Documents

• Specification Sheet
