LGFS04HPX - Eaton Molded Case Circuit Breaker Accessory Handle Mechanism

Eaton Molded Case Circuit Breaker Accessory Handle Mechanism is engineered for demanding environments where remote breaker operation is essential. This high-performance flex shaft flange-mounted handle mechanism is designed for LG-frame circuit breakers in the Series G lineup. With a 4-foot shaft and a NEMA 4/4X enclosure rating, it provides reliable protection against dust, water, and corrosion, making it ideal for outdoor or industrial applications.

Key Features:

• Handle Type: High Performance Flex Shaft Flange-Mounted
• Frame Compatibility: LG-Frame
• Series: Series G
• Shaft Length: 4 FT
• Enclosure Rating: NEMA 4/4X

This handle mechanism ensures safe and effective circuit breaker control, even in rugged conditions.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Application of Tap Rules to Molded Case Breaker Terminals

Brochures
Multi-wire lugs product aid
High performance operating handles for Series G circuit breakers product aid

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Multimedia
Flex shaft handle installation tutorial

Specifications and datasheets
MOEM MCCB product selection guide
